First Pass Yield

First pass yield (FPY) is a metric that indicates the percentage of items moving through a series of processes without any problems.

The basic equation for first pass yield is:

First Pass Yield = Process 1 Yield * Process 2 Yield *…*Process ‘n’ Yield

First Pass Yield Demo

Click the image to see it in full size.

As you can see, the more process steps you have, the more challenging it will be to get an item through the system without any issues. For example, consider an operation that has 4 processes, each with a yield of 95%.

Using the first pass yield equation above, the FYP is:

.95 x .95 x .95 x .95 = .81

That means that even with 4 processes performing at a 95% yield, one out of every 5 products will not make it through your system without needing rework.

Read more about this topic below.

If you like this reference guide, please help us spread the word about it!

As you can infer from the equation, the effectiveness of a process plays a big role in determining first pass yield. But the total number of processes also has a huge impact. One of the areas where Lean really shines is in simplification. Reduce the number of processes that it takes to produce a product, and you also reduce the number of chances to make a mistake.

It is also worth noting that looking at quality numbers for individual processes can be misleading from a system perspective. As you can see from the example above, it doesn’t take long for defect rates to stack up. With four processes having a 95% yield, good product only roll off the line without any rework 81% of the time. Even at 97% or 98% yield for processes, the rolled through yield can be dramatically lower than the individual processes.

Rework and First Pass Yield

Most processes have hidden factories built in. There are corrective actions a person takes when they see a problem. This rework is almost never included on work instructions, and seldom shows up in any form of quality log. For that reason, first pass yield is often underestimated.

Make sure that if you really want to improve quality, you find a way to track this sort of activity. Be clear that it is not intended to be punitive. People will protect each other. The goal should be to improve processes.

Units vs. Total Defects

Note that this metric is used on a unit basis. An item is considered a fail whether it has one or multiple defects. Other metrics (i.e. PPMO, or defects per million opportunities) can be a better judge of quality when products have numerous issues or a significant number of process steps.

Rolled Through Yield vs. First Pass Yield

One of the challenges with terminology is that with no governing body, the meaning can be different for various groups. Accounting, for example, is governed by a handful of organizations (i.e. the IRS, GAAP, etc.) that define the meaning of terms.

With regards to this term, though, there is no governing body for quality or Lean. (There are some major players like ISO, but they don’t have the same sort of authority as the governmental agencies listed above.) For that reason, you will likely see some differences in how this metric is named. First pass yield may be called first time yield. And it may also be called rolled through yield or rolled throughput yield.

It is also worth noting that a quick internet search will yield some variation in the meaning of the terms. While we recommend using the term first pass yield with the calculation described above, if you choose something else, be sure it is clearly understood throughout your company.

  • Be careful about rework. Often items are fixed within a process and don’t show up as a defect. Other times, work is added back into the system. Make sure that the measurement system you use to track first pass yield clearly defines how to handle these issues.
  • One of the challenges in understanding first pass yield is the lack of visibility. Because most frontline workers want to do a good job, they fix problems on the spot, or help out their upstream coworkers. As a result defects are not recorded, making the first pass yield rate look better than it really is.
